Fins material : | Aluminium |
Maximum airflow : | 75.3 cfm |
Product colour : | Black |
Width : | 125 mm |
Depth : | 83 mm |
Height : | 155 mm |
Power consumption (typical) : | 6 W |
Quantity per pack : | 1 pc(s) |
Thermal Design Power (TDP) : | 230 W |
Rated voltage : | 12 V |
Type : | Air cooler |
Fan speed (max) : | 1800 RPM |
Fan diameter : | 12 cm |
Mean time between failures (MTBF) : | 60000 h |
Rated current : | 0.5 A |
Bearing type : | Hydraulic |
Supported processor sockets : | LGA 2011 (Socket R) |
Supported processor sockets : | LGA 1150 (Socket H3) |
Supported processor sockets : | LGA 1700 |
Supported processor sockets : | LGA 1156 (Socket H) |
Supported processor sockets : | Socket AM4 |
Supported processor sockets : | LGA 1155 (Socket H2) |
Supported processor sockets : | LGA 2066 |
Supported processor sockets : | LGA 1151 (Socket H4) |
Supported processor sockets : | LGA 1200 (Socket H5) |
Fan dimensions (W x D x H) : | 120 x 120 x 25 mm |
Heat pipes diameter : | 6 mm |
Suitable location : | Processor |
Starting voltage : | 5 V |
Fan connector : | 4-pin |
Maximum air pressure : | 3.04 mmH2O |
Number of heat pipes : | 4 |
Minimum air pressure : | 1.38 mmH2O |
Minimum airflow (imperial) : | 37.1 cfm |
Fan speed (min) : | 800 RPM |
Fan noise level (max) : | 34 dB |
Base plate material : | Aluminium |
Fan noise level (min) : | 17 dB |
